BMW N54 Engine Workshop Manual. EWD
BMW N54 2008+ This is a 6-cylinder engine with a capacity of 2979 cc. It is a 6-cylinder in-line engine driven by a timing chain timing system. It has an aluminum cylinder head with 4 valves per cylinder. Fuel is supplied by the DME system. Its operating order is 1-5-3-6-2-4.
2008 Bmw 135i Repair Manual Pictures of repair procedures and detailed instructions for the mechanics of the engines installed on the vehicle. In addition, you will find manufacturer data and specifications for more precise repairs.
Engine mechanics BMW N54
- Engine installed: BMW 135 E82, BMW 335i E90, BMW 535i E60, BMW 740i F01, BMW X6 E71, BMW Z4 E89,
- Engine brand: N54
- Years of production: 2006-2016
- Type: in-line
- Number of cylinders: 6
- Engine weight, kg: ~187
- How much oil is in the engine, l: 6.5
- Engine oil: 5W-30 5W-40
- Engine life, thousand km: ~300
BMW N54B30 engine modifications
1. N54B30O0 (2006 - 2010 onwards) - base engine with 306 hp. at 5800 rpm, torque 400 Nm at 1400-5000 rpm. For versions with index 35i.
2. N54B30 (2008 - 2012 onwards) - version for BMW 740i and 335si, 326 hp. at 5800 rpm, torque 450 Nm at 1500-4500 rpm. Differences from the standard in the fan, radiator and ECU firmware.
3. N54B30T0 (2010 - present year) - 340 hp version. at 5900 rpm, torque 450 Nm/500 Nm Overboost at 1500-4500 rpm. The differences between the N54B30T0 are the improved cooling system (fan, radiator) and ECU firmware. The engine was produced for the BMW 1M and BMW Z4 E89 sDrive35is.
Download free BMW N54 Repair Manual
| BMW 135i 2008 N54 Engine Repair Instruction | Download |
| BMW 135i 2009 N54 Engine Repair Instruction | Download |
| BMW 135i 2010 N54 Engine Repair Instruction | Download |
| Bmw 335i 2007-2008 N54 335i, 335xi Engine Repair | Download |
| Bmw 335i 2008 N54 335i, 335xi Engine Repair | Download |
| Bmw 335i 2009 N54 335i, 335xi Engine Repair | Download |
| Bmw 335i 2010 N54 335i, 335xi Engine Repair | Download |
| Bmw 535i 2008 N54 Repair Instructions | Download |
| Bmw 535i 2009 N54 Repair Instructions | Download |
| Bmw 535i 2010 N54 Repair Instructions | Download |
| Bmw X6 35i 2008 N54 Engine - Repair Instructions | Download |
| Bmw Z4 30i 2010 N54 Engine - Repair Instructions | Download |
| Download |
Reliability, problems and repair of the BMW N54B30 engine
The powerful N54 twin-turbocharged inline-six was developed by Alpina in 2006 for fast civilian cars and BMW crossovers. The basis was an aluminum cylinder block M54B30 with cast iron liners, covered on top with a new cylinder head with a Bi-VANOS variable valve timing system on the intake and exhaust shafts and direct fuel injection. The diameter of the intake valves is 31.44 mm, exhaust valves 28 mm. Characteristics of camshafts on N54 (intake/exhaust): phase 245/261 lift 9.7 mm. There is no Valvetronic valve lift system here. Supercharging is realized using two Mitsubishi TD03-10TK3 turbochargers, blowing in parallel, each into its own three cylinders. The boost pressure on a standard engine is 0.55 bar. Siemens MSD 80/MSD 81 engine management system.
The N54B30 engine was used in BMW cars with the 35i index (40i for the 7-Series). In addition, the engine was used by Alpina, modified to 360 hp. and 400 hp options.
A replacement for the engine came out in 2009, when the Munich team introduced a new generation of in-line turbocharged six - N55B30.
